High Speed Thermoforming Machine
Model: RS-730-800-3
RS-730-800-3 High Speed Thermoforming Machine， uses internationally advanced plastic sheet forming technology. It is a plastic sheet formi...
Energy-saving Plastic Thermoforming Machine for plastic injection trays
Model：RS-730-800-3
INTRODUCTION
As the medical packaging industry evolves, demand for high-precision, efficient, and validation-ready injection tray production grows—and the Injection Tray Thermoforming Machine is at the forefront of this innovation. A specialized upgrade of the traditional Plastic Thermoforming Machine, this equipment integrates cutting-edge engineering, intelligent controls, and injection tray-specific design features to deliver exceptional performance, helping enterprises stay competitive in the strict medical packaging market.
The Injection Tray Thermoforming Machine incorporates an innovative heating system, a significant advancement over standard Plastic Thermoforming Machines. Using infrared segmented heating, it precisely controls the temperature of each area of the plastic sheet (PET, PP, or PS), ensuring uniform heating that maintains material integrity and produces consistent, high-quality injection trays. This system reduces heating time by 20% compared to conventional Plastic Thermoforming Machines, improving production efficiency while minimizing energy consumption. Its heat insulation design further enhances energy savings, aligning with modern green production trends without compromising the strict quality standards required for medical injection trays.
In terms of design, the Injection Tray Thermoforming Machine combines humanization and intelligence, building on the best features of advanced Plastic Thermoforming Machines. Its full-color touch-screen interface is intuitive and easy to operate, allowing operators to adjust parameters, monitor production status, and access stored injection tray mold settings with just a few clicks. The parameter save function is optimized for the unique requirements of medical mold sets, supporting hundreds of validated parameters—from small syringe trays to large multi-cavity injection trays—enabling quick production switches and reducing setup time. An automatic safety protection system prevents accidents caused by misoperation, ensuring operator safety and equipment integrity in cleanroom medical production environments.
While specialized for injection and syringe tray production, this Plastic Thermoforming Machine variant retains impressive versatility, supporting PET, PP, and PS materials to accommodate diverse medical and general packaging demands. Its 45 molds per minute maximum speed for thin-gauge PET sets it apart from standard Plastic Thermoforming Machines, making it ideal for high-volume medical injection tray production. The machine’s precise forming and punching capabilities ensure every injection tray meets the highest standards of precision, clarity, and functionality—from sterile syringe holders to tamper-evident blister packs. With its advanced technology, stable performance, and validation readiness, the Injection Tray Thermoforming Machine is redefining what a specialized Plastic Thermoforming Machine can achieve, becoming the first choice for modern medical packaging manufacturers.
MACHINE STRUCTURE
PRODUCTS RANGE
FEATURES AND ADVANTAGES
1. High degree of standardization, complete functions, safe, efficient, energy-saving and hygienic.
2. It integrates mechanical, pneumatic and electrical integration, and is controlled by microcomputer and programmable controller (PLC).
3. Easy-to-operate human-machine interface, and has the function of remote connection.
4. Electric lifting, double-station large-diameter unwinding, allowing a single person to load coils weighing up to 600KG.
5. Servo feeding, stepless adjustment of sheet length, high speed, accuracy and stability.
6. The upper and lower electric heating furnaces are used for four-stage heating and protection to reduce the impact of air convection on temperature, so that the product molding is stable, from 0-400 degrees in just 3 minutes, improving production efficiency. The electric heating furnace can automatically remove the device.
7. A new real-time distributed digital dynamic hot forming temperature control system is used to control the temperature of the tile at a single point, and it has automatic compensation control, with an accuracy of ±1℃. Energy saving of about 15% and extended furnace plate service life.
8. The quick mold change system can conveniently, quickly, accurately and safely change molds, reduce machine downtime, reduce labor waste, and improve production efficiency.
9. The mold opening and closing of the forming, punching and cutting stations are controlled by servo motors, with high precision, low wear, fast speed and low noise. Each station is supported by four columns, combined with a five-point structural connecting rod, which has good stability.
10. The unique vertical stacking concept ensures continuous stacking of products.
11. Automatic counting of finished product output, with production data memory function, can store 90 sets of operating data.
12. Combined with the edge material winding device, the entire production process is clean, without burrs and waste.
13. The design of the electrical cabinet is simple and refreshing, simplifying the machine assembly and wiring installation process.
SPECIFICAITON
|
Sheet Materials |
PP/PS/PET/PLA/PE/CPET |
Air Consumption |
4m³/min |
|
Sheet Thickness |
0.2-1.5mm |
Weight |
14500kg |
|
Forming Area |
730*800mm |
Total Installed Power |
185kw |
|
Width Of Sheet |
400-800mm |
Heating Power |
140kw |
|
Upper Forming Depth |
100mm |
Feeding Motor |
4.4kw |
|
Bottom Forming Depth |
130mm |
Control Forming Plug Motor Power |
4.4kw |
|
Max Speed |
48 moulds/min |
Stacking Motor |
2.9kw |
|
The Longest Knife |
12m |
Winding Waste Of Edge Sheet Motor Power |
0.4kw |
|
Dimension |
11500*2350*2700mm |
Forming Motor |
7.5kw*2 |
|
Forming clamping force |
750kn |
Cutting Motor |
7.5kw*1 |
|
Punching clamping force |
900kn |
|
|
