Thermoforming Machine

Four-Station Plastic forming machine

Four-Station Plastic forming machine

Model：RS-730-800-4
RS-730-800-4 positive and negative pressure multi-station plastic thermoforming machine， uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...
Three-Station Plastic Thermoforming Machine

Three-Station Plastic Thermoforming Machine

Model：RS-730-800-3
RS-730-800-3 positive and negative pressure multi-station plastic thermoforming machine， uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...
Four-Station Plastic Thermoforming Machine

Four-Station Plastic Thermoforming Machine

Model：RS-730-610-4
RS-730-610-4 positive and negative pressure multi-station plastic thermoforming machine， uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...
Four-Station Plastic Thermoforming Machine

Four-Station Plastic Thermoforming Machine

Model：RS-650-450-4
RS-650-450-4 positive and negative pressure multi-station plastic thermoforming machine， uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...

Professional Plastic Box Making Machine for Industrial Packaging

2026-01-11
Industrial packaging requires precision and durability, and Wenzhou Rayshape Machinery Co., Ltd. provides both with our Professional Plastic Box Making Machine. As a subsidiary of Elemotion Group, we focus on high-end automation for the global market. Our Plastic Box Making Machine is ideal for producing a variety of containers, including electronic component boxes and retail packaging. Located in Pingyang County, Wenzhou, we integrate mechanical and software R&D to deliver equipment that is both stable and reliable. The machine utilizes high-speed Plastic Thermoforming Machine technology, capable of processing PET at 45 molds per minute and PP at 30 molds per minute. This high-speed performance is complemented by our multi-station configuration, which streamlines the forming, cutting, and stacking processes. We offer versatile plate surfaces like 650 by 450 and 730 by 610 to suit different production needs. The future-oriented control system is a key feature of our equipment, offering an intelligent parameter save function. This allows for the permanent storage of optimized settings, making it easy to resume production without repetitive debugging. Rayshape is committed to innovation and learning from Elemotion’s path to becoming an industry leader. Our plastic sheet extrusion lines and roll forming machines are compatible with materials like C-PET, BOPS, and HIPS. We boast a seasoned after-sales service team and a solid financial foundation, ensuring that our customers receive the support they need to maintain a competitive edge. By choosing Rayshape, you are investing in energy-efficient, highly automated machinery that is built to deliver high-quality finished products consistently.
Thermoforming Machine
Plastic Thermoforming Machine
Plastic forming machine
Plastic Container Machine
← Back Plastic Thermoforming Machine.pdf

Specifications Of Thermoforming Machines

Sheet Materials

PP/PS/PET/PLA/PE

Air Consumption

3m³/min
0.5-0.8bar

Sheet Thickness

0.2-1.5mm

Weight

11000kg

Forming Area

650*450mm

Total Installed Power

116Kw

Width Of Sheet

370-700mm

Heating Power

90kw

Upper Forming Depth

100mm

Feeding Motor

3kw

Bottom Forming Depth

130mm

Control Forming Plug Motor Power

3kw

Max Speed

45moulds/min

Stacking Motor

1.8kw

The Longest Knife

8m

Winding Waste Of Edge Sheet Motor Power

0.4kw

Dimension

10210*2300*2700mm

Forming Motor

4.4kw*2

Forming clamping force

600kn

Cutting Motor

4.4kw*2

Punching clamping force

600kn



Advantages Of Plastic Thermoforming Machines

Loading sheet part

Loading sheet part

Load automatically, lower human resource cost.

Proximity switch clever control, getting the rid of falling down of the sheet by conveying too fast.

Double stations, big diameter, reduce the frequency of changing sheet coil, improve the the production efficiency.

Max undertake roll of sheet

Weight:600kg, Diameter 800mm.

Feeding sheet part

Feeding sheet part

Automatic feeding reduces human resource costs.

Actively transport the sheet and reduce the load on the conveying servo motor.

Cleverly control the proximity switch to prevent the sheet from falling too quickly during transportation.

Human-machine interface

Human-machine interface

Controlled by microcomputer and programmable controller (PLC), all action programs can be operated through the human-machine interface, simple and convenient, 15-inch touch screen.

Heater

Heater

1. Vacuum insulation cotton is installed in the heater, which has a fast reaction speed, short processing time and energy saving.

2. The furnace body is divided into two layers, the layout of the heating tiles is optimized, so that the plate is heated evenly.

Molding station

Molding station

1. Mold changing auxiliary mechanism, using sliding guide rails and support rods to achieve fast mold change, saving time and effort.

2. Adopting high-power servo motor drive, high precision, high efficiency and low noise.

Molding mold

Molding mold

The working principle is a combination of positive and negative pressure, and some nylon plugs are used to assist stretching in the mold to make it have stronger molding ability.

There is cooling water in the mold cavity to speed up the cooling speed and make demolding easier.

Guide head structure

Guide head structure

The workstation is supported by four columns (45# steel, hard chrome plated).

The integrated mold table (QT-600 steel) is made by a high-precision CNC milling machine. Therefore, it is wear-resistant, stable, and accurate, which prolongs the service life of the equipment.

A five-point-connecting-rod structure

A five-point-connecting-rod structure

This structure design provides more stable operation and faster speed.

Mold change structure

Mold change structure

The punching hole station has the same mold changing structure as the cutting station.Greatly reduce mold change time and labor costs, improve production efficiency and safety factor, and provide convenience for your diversified product chain.

Servo motor

Servo motor

The station mold closing, forming auxiliary stretching, and pull-tab parts are all driven by servo motors, which have fast speed, low noise, high precision, and high efficiency.

Servo-controlled conveyor belt

Servo-controlled conveyor belt

Set conveyor belt parameters directly on the operation screen.

Freely adjust and control conveying length and speed.

Rewinding waste of edge sheet

Rewinding waste of edge sheet

Our multi-station thermoformers feature a winding unit with torque motor to efficiently collect the offcuts and wind them into a roll with one side retractable, which can be conveniently removed at the end of production.

This advanced waste management system improves operating efficiency and cleanliness, making multi-station thermoformers ideal for high-quality and sustainable production.
