Thermoforming Machine

Four-Station Plastic forming machine

Model:RS-730-800-4
RS-730-800-4 positive and negative pressure multi-station plastic thermoforming machine, uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...

Three-Station Plastic Thermoforming Machine

Model:RS-730-800-3
RS-730-800-3 positive and negative pressure multi-station plastic thermoforming machine, uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...

Four-Station Plastic Thermoforming Machine

Model:RS-730-610-4
RS-730-610-4 positive and negative pressure multi-station plastic thermoforming machine, uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...

Four-Station Plastic Thermoforming Machine

Model:RS-650-450-4
RS-650-450-4 positive and negative pressure multi-station plastic thermoforming machine, uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...

A leading force in the field of plastic thermoforming

2018-06-25

In the rapidly developing modern manufacturing industry, plastic thermoforming technology has become an indispensable part of packaging, food, medicine, electronics and other industries with its high efficiency, flexibility and wide application. In this booming field, Wenzhou Ruisu Machinery Co., Ltd. is steadily growing into a trusted partner of global customers with its excellent plastic thermoforming machine products and profound technical accumulation.

Core products: Creating automated and efficient thermoforming solutions

As a company specializing in the research and development and manufacturing of plastic thermoforming machines and supporting equipment, Wenzhou Ruisu knows that excellent equipment is the key to customer success. Its core product series include:

Fully automatic multi-station thermoforming machine: Representing the forefront of efficient production, realizing continuous, multi-process integrated operations, significantly improving production capacity and reducing labor costs.
RS series fully automatic thermoforming machine: Combining the advantages of stability, precision and automation, it is a reliable choice to meet diverse thermoforming needs and ensure product quality consistency.
Multifunctional thermoforming machine: Demonstrating flexible adaptability, adapting to the processing needs of products of different materials and shapes, helping customers to respond quickly to market changes.
RS series plastic cover forming machine: Provide professional cover product production solutions, mature technology, and outstanding quality.
Each Ruisu thermoforming machine condenses more than ten years of technical intensive cultivation and innovation. The company knows that high-quality sheets are the basis of molding quality. Therefore, Wenzhou Ruisu also has an advanced RS series plastic sheet extruder product line, including single-layer, double-layer and PET-specific extruders, forming a complete process chain from raw materials to finished products, providing customers with integrated equipment supply and technical support.

Strong foundation: solid guarantee of R&D strength and global network

Wenzhou Ruisu is headquartered in Pingyang County, Wenzhou City, Zhejiang Province, a major manufacturing town. The company has established a large-scale R&D institution in the same industry in China, continuously invested in technological innovation, and focused on improving equipment performance, intelligence level and energy efficiency. Years of concentrated precipitation have made product quality achieve a qualitative leap.

Strong R&D is inseparable from the support of a complete production and marketing service system. Wenzhou Ruisu has not only built a sales and service network covering the whole country, but also set its sights on the world. At present, the company's products have been exported to more than 60 countries and regions including Europe, North America, Southeast Asia, West Asia, the Middle East, Africa, and South America. Its stable performance and perfect service have won wide recognition in the international market. The company's machinery and equipment have been successfully used in many key production links in the food, medicine, printing, packaging and other industries.

Customer-centric: Eternal commitment to quality, service and innovation

Wenzhou Ruisu regards "quality excellence, customer first, quality service, and continuous improvement" as the company's core policy, and "striving for innovation for the benefit of customers" as its unremitting mission. This is not only reflected in the pursuit of excellence in equipment manufacturing, but also throughout the customer service of the entire life cycle.

Join hands with Ruisu to create brilliance

Wenzhou Ruisu Machinery Co., Ltd. is well aware that plastic thermoforming is not only the operation of the machine, but also the key process of shaping the indispensable materials of modern life. The company will continue to adhere to the foundation of quality, deepen technological innovation, expand the global service network, and always take the success of customers as its own responsibility.

Choosing Wenzhou Ruisu means choosing a plastic thermoforming equipment partner with leading technology, trustworthiness, and comprehensive services. No matter where you are in the world, Ruisu will wholeheartedly provide you with efficient, stable and intelligent thermoforming solutions, and jointly open a new chapter in plastic molding technology!


Thermoforming Machine
Plastic Thermoforming Machine
Plastic forming machine
Plastic Container Machine

Specifications Of Thermoforming Machines

Sheet Materials

PP/PS/PET/PLA/PE

Air Consumption

4m³/min
0.5-0.8bar

Sheet Thickness

0.2-1.5mm

Weight

15500kg

Forming Area

730*610mm

Total Installed Power

185kw

Width Of Sheet

400-800mm

Heating Power

140kw

Upper Forming Depth

100mm

Feeding Motor

4.4kw

Bottom Forming Depth

130mm

Control Forming Plug Motor Power

4.4kw

Max Speed

45moulds/min

Stacking Motor

1.8kw

The Longest Knife

10m

Winding Waste Of Edge Sheet Motor Power

0.4kw

Dimension

12785*2350*2700mm

Forming Motor

5.5kw*2

Forming clamping force

750kn

Cutting Motor

5.5kw*2

Punching clamping force

750kn

Punching Motor

5.5kw*2

Advantages Of Plastic Thermoforming Machines

Loading sheet part

Loading sheet part

Load automatically, lower human resource cost.

Proximity switch clever control, getting the rid of falling down of the sheet by conveying too fast.

Double stations, big diameter, reduce the frequency of changing sheet coil, improve the the production efficiency.

Max undertake roll of sheet

Weight:600kg, Diameter 800mm.

Feeding sheet part

Feeding sheet part

Automatic feeding reduces human resource costs.

Actively transport the sheet and reduce the load on the conveying servo motor.

Cleverly control the proximity switch to prevent the sheet from falling too quickly during transportation.

Human-machine interface

Human-machine interface

Controlled by microcomputer and programmable controller (PLC), all action programs can be operated through the human-machine interface, simple and convenient, 15-inch touch screen.

Heater

Heater

1. Vacuum insulation cotton is installed in the heater, which has a fast reaction speed, short processing time and energy saving.

2. The furnace body is divided into two layers, the layout of the heating tiles is optimized, so that the plate is heated evenly.

Molding station

Molding station

1. Mold changing auxiliary mechanism, using sliding guide rails and support rods to achieve fast mold change, saving time and effort.

2. Adopting high-power servo motor drive, high precision, high efficiency and low noise.

Molding mold

Molding mold

The working principle is a combination of positive and negative pressure, and some nylon plugs are used to assist stretching in the mold to make it have stronger molding ability.

There is cooling water in the mold cavity to speed up the cooling speed and make demolding easier.

Guide head structure

Guide head structure

The workstation is supported by four columns (45# steel, hard chrome plated).

The integrated mold table (QT-600 steel) is made by a high-precision CNC milling machine. Therefore, it is wear-resistant, stable, and accurate, which prolongs the service life of the equipment.

A five-point-connecting-rod structure

A five-point-connecting-rod structure

This structure design provides more stable operation and faster speed.

Mold change structure

Mold change structure

The punching hole station has the same mold changing structure as the cutting station.Greatly reduce mold change time and labor costs, improve production efficiency and safety factor, and provide convenience for your diversified product chain.

Servo motor

Servo motor

The station mold closing, forming auxiliary stretching, and pull-tab parts are all driven by servo motors, which have fast speed, low noise, high precision, and high efficiency.

Servo-controlled conveyor belt

Servo-controlled conveyor belt

Set conveyor belt parameters directly on the operation screen.

Freely adjust and control conveying length and speed.

Rewinding waste of edge sheet

Rewinding waste of edge sheet

Our multi-station thermoformers feature a winding unit with torque motor to efficiently collect the offcuts and wind them into a roll with one side retractable, which can be conveniently removed at the end of production.

This advanced waste management system improves operating efficiency and cleanliness, making multi-station thermoformers ideal for high-quality and sustainable production.
