Multifunctional thermoforming machine

Model:550

Contact Details

WhatsApp: 8615355870907
Email: zhu@cnrayshape.com
Address: No. 19, East Section of Pinghai road,Binhai New District, Pingyang County, Wenzhou City, Zhejiang Province

Product Details

We design for PP and PS PVC films. This machine is suitable for any thermoforming plastic sheet. This plastic thermoforming machine is upgraded according to the latest development technology, and it solves many unsolvable problems compared to traditional machines. This plastic thermoforming machine forms and cuts neatly and clearly, and can cut off products in sequence. Also suitable for PP, PS, PET, PVC, etc.
The whole machine is mainly composed of four parts:
Raw material preforming, product forming, punching, punching, product stacking

Model
550
Punching time
10-24 times/minute
Raw materials
PP/PS/PET/PVC/PLA
Forming area
550*350*80mm
Heating power 65KW
Total power 380V 50HZ 80KW
Water consumption 0.3m²/h (tap water or circulating water)
Air pressure 0.5-0.8MPa
Water supply pressure 0.2MPa
Dimensions (length x width x height) 5950*1725*1900mm
Floor space 8700*3600
Maximum plastic coil diameter 600mm
Maximum cutting force 30 tons
Total weight 5500KG
