RS Series Plastic Cap Forming Machine
Model:420 / 450
Contact Details
WhatsApp:
8615355870907
Email:
zhu@cnrayshape.com
Address:
No. 19, East Section of Pinghai road,Binhai New District, Pingyang County, Wenzhou City, Zhejiang Province
Product Details
1. This machine is designed and manufactured in accordance with the "GMP" standard of the pharmaceutical industry and the "QS" standard of the food industry.
2. This machine can complete forming, punching and cutting at the same time to avoid cross contamination of products.
3. The forming heating plate can be automatically turned on and off, and can be delayed to start, so as to control and reduce the waste of materials in the production process.
4. The mold is easy to replace and is suitable for products of different specifications.
5. The mold can be designed according to customer requirements.
6. Applicable projects: HIPS, PVC, PET and other materials.
Model |
420 |
450 |
Cutting frequency |
15--45(times/min) |
15-45(times/min) |
Power |
380v/220v/50HZ |
380v/220v/50HZ |
Adjustable stroke range | 160mm | 260mm |
Maximum molding depth | 50mm | 50mm |
Maximum molding area |
420×160mm |
450*260mm |
Motor power | 4kw | 8kw |
Power consumption |
>0.2m3/min |
>0.2m3/min |
Pressure |
0.4--0.7mpa |
0.4-0.7mpa |
Dimensions |
2500*1600*1000mm |
2900*1800*1000mm |
Weight |
1300kg |
1800kgs |
