Upholding Quality, Rebuilding the Reputation of Wenzhou Thermoforming Machines — RAYSHAPE

2026-04-07
Lan

Written by

Lan

Chief Mechanical Engineer

A rare female engineer in the mechanical engineering industry, with over 20 years of experience, possessing both professional depth and a holistic perspective in areas such as technical control, team coordination, project implementation, and risk assessment.

Wenzhou, a globally renowned hub for machinery manufacturing, enjoys an international reputation in food packaging machines, vacuum packaging machines and other fields. It has nurtured a group of benchmark enterprises including ELEMOTION , Reador ,and Hengfeng Machinery, which have promoted "Made in Wenzhou" to the global market with outstanding strength.

However, in the thermoforming machine segment, affected by the extensive development model in the early days of the industry, Wenzhou thermoforming machines once suffered from reputation challenges such as unstable quality, inadequate after-sales service and quality degradation caused by low-price competition. These problems not only restricted the expansion of the domestic market, but also undermined overseas customers’ trust in the regional brand, hindering the high-end and branded development of the industry for a long time.

Faced with industry difficulties and brand pressure, RAYSHAPE, a high-end thermoforming machine brand backed by ELEMOTION, has adhered to the development strategy of high-end, quality-oriented and service-focused since its establishment. The company rejects vicious low-price competition, sticks to manufacturing standards, and takes the initiative to shoulder the responsibility of reversing the industry’s reputation and rebuilding the regional brand image with reliable equipment and comprehensive services.
Relying on the parent company’s mature R&D system, strict quality control process and high-quality supply chain resources, RAYSHAPE specializes in the R&D and manufacturing of high-end equipment such as positive and negative pressure integrated thermoforming machines, multi-station integrated thermoforming machines, full-servo thermoforming machines and high-speed thermoforming machines. The company implements high-standard quality control throughout the whole process from component selection, production and assembly to factory inspection and after-sales response, creating high-end thermoforming equipment with stable performance, high efficiency, energy saving and high durability.
Verified by the market for a long time, the company’s equipment has reached the advanced industry level in core indicators such as operation stability, forming accuracy, production speed and energy consumption control, winning wide recognition from customers at home and abroad.
From deep cultivation in overseas markets to expansion in the domestic market, RAYSHAPE has always taken "clearing the name of Wenzhou thermoforming machines and rebuilding the reputation of Wenzhou intelligent manufacturing" as its core goal, breaking market prejudices with product strength.
At present, thermoforming equipment is upgrading towards high speed, intelligence, precision and stability, and the demand for high-quality equipment continues to grow. Adhering to the philosophy of customer-centricity, technology-driven development and reputation-oriented goals, the company continuously optimizes product performance and upgrades its service system, accumulating brand trust with every high-quality piece of equipment and every efficient service, and gradually changing the market’s inherent impression of Wenzhou thermoforming machines.
In the future, RAYSHAPE will continue to uphold the philosophy of "Precision Manufacturing, Quality First", unite with industry counterparts to reject low-price competition, stick to the bottom line of quality, and jointly promote the Wenzhou thermoforming machine industry to move towards high-end, branded and international development. We will let the world rediscover Wenzhou thermoforming machines and help "Made in Wenzhou" achieve new glory in the field of high-end thermoforming equipment.
Thermoforming Machine
Plastic Thermoforming Machine
Plastic Forming Machine
Plastic Container Machine

Plastic Thermoforming Machine

Four-Station Plastic forming machine

Model:RS-750-800-4
RS-750-800-4 positive and negative pressure multi-station plastic thermoforming machine, uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...

Three-Station Plastic Thermoforming Machine

Model:RS-750-800-3
RS-750-800-3 positive and negative pressure multi-station plastic thermoforming machine, uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...

Four-Station Plastic Thermoforming Machine

Model:RS-750-610-4
RS-730-610-4 positive and negative pressure multi-station plastic thermoforming machine, uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...

Four-Station Plastic Thermoforming Machine

Model:RS-650-450-4
RS-650-450-4 positive and negative pressure multi-station plastic thermoforming machine, uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...

Advantages Of Plastic Thermoforming Machines

Loading sheet part

Loading sheet part

Load automatically, lower human resource cost.

Proximity switch clever control, getting the rid of falling down of the sheet by conveying too fast.

Double stations, big diameter, reduce the frequency of changing sheet coil, improve the the production efficiency.

Max undertake roll of sheet

Weight:600kg, Diameter 800mm.

Feeding sheet part

Feeding sheet part

Automatic feeding reduces human resource costs.

Actively transport the sheet and reduce the load on the conveying servo motor.

Cleverly control the proximity switch to prevent the sheet from falling too quickly during transportation.

Human-machine interface

Human-machine interface

Controlled by microcomputer and programmable controller (PLC), all action programs can be operated through the human-machine interface, simple and convenient, 15-inch touch screen.

Heater

Heater

1. Vacuum insulation cotton is installed in the heater, which has a fast reaction speed, short processing time and energy saving.

2. The furnace body is divided into two layers, the layout of the heating tiles is optimized, so that the plate is heated evenly.

Molding station

Molding station

1. Mold changing auxiliary mechanism, using sliding guide rails and support rods to achieve fast mold change, saving time and effort.

2. Adopting high-power servo motor drive, high precision, high efficiency and low noise.

Molding mold

Molding mold

The working principle is a combination of positive and negative pressure, and some nylon plugs are used to assist stretching in the mold to make it have stronger molding ability.

There is cooling water in the mold cavity to speed up the cooling speed and make demolding easier.

Guide head structure

Guide head structure

The workstation is supported by four columns (45# steel, hard chrome plated).

The integrated mold table (QT-600 steel) is made by a high-precision CNC milling machine. Therefore, it is wear-resistant, stable, and accurate, which prolongs the service life of the equipment.

A five-point-connecting-rod structure

A five-point-connecting-rod structure

This structure design provides more stable operation and faster speed.

Mold change structure

Mold change structure

The punching hole station has the same mold changing structure as the cutting station.Greatly reduce mold change time and labor costs, improve production efficiency and safety factor, and provide convenience for your diversified product chain.

Servo motor

Servo motor

The station mold closing, forming auxiliary stretching, and pull-tab parts are all driven by servo motors, which have fast speed, low noise, high precision, and high efficiency.

Servo-controlled conveyor belt

Servo-controlled conveyor belt

Set conveyor belt parameters directly on the operation screen.

Freely adjust and control conveying length and speed.

Rewinding waste of edge sheet

Rewinding waste of edge sheet

Our multi-station thermoformers feature a winding unit with torque motor to efficiently collect the offcuts and wind them into a roll with one side retractable, which can be conveniently removed at the end of production.

This advanced waste management system improves operating efficiency and cleanliness, making multi-station thermoformers ideal for high-quality and sustainable production.
