Plastic Seedling Tray Making Machine for Greenhouse Nursery

▶

Plastic Seedling Tray Making Machine for Greenhouse Nursery

Model：RS-730-800-3

Contact Details

WhatsApp： 8615355870907

Email： zhu@cnrayshape.com

PDF Download Enquire Now

INTRODUCTION

In the competitive horticultural market, custom seedling trays and plant pots are essential for specialized cultivation—from vegetable seedlings to ornamental flowers—and our Seedling Tray Making Machine is purpose-built to meet this demand. As a precision-focused iteration of our multi-station Plastic Thermoforming Machine, it combines ultra-high dimensional accuracy with automated production, ensuring every tray and pot meets the strict specifications of commercial nurseries and home gardeners alike. Unlike standard thermoforming equipment, this machine is engineered to handle both standard mass production and small-batch custom orders, making it a versatile asset for horticultural manufacturers.
The system’s modular three-station and four-station designs form the backbone of its flexibility. The four-station configuration, featuring an integrated precision punching unit, ensures clean, burr-free edges on custom seedling trays and deep-draw plant pots—critical for healthy root development and easy transplanting. This integration streamlines the production workflow, reducing material waste and production time compared to standalone thermoforming and trimming setups. The Seedling Tray Making Machine is fully capable of manufacturing a diverse range of horticultural products, including multi-cell propagation trays, round/ square plant pots, and specialized seedling containers for commercial greenhouse operations.
Performance and material versatility are hallmarks of this machine. It excels at processing PS, PP, and PET, with speed tailored to material and product type: PET (for clear, durable trays) reaches 45 molds per minute, while PP and PS (for cost-effective, lightweight containers) hit 30 molds per minute. For custom designs—such as deep-dive pots or irregularly shaped seedling trays—forming time is extended to maintain precision, a capability the machine’s adaptive control system manages seamlessly. This balance of speed, flexibility, and accuracy makes it suitable for both high-volume commercial runs and low-volume custom production.
At the core of the Seedling Tray Making Machine is a future-ready control system with a specialized parameter storage function. Each custom mold, whether for a specific seedling size or unique pot design, has its optimized operating parameters permanently saved in the system. After initial debugging and validation by our engineering team, these settings are instantly accessible for future production runs. Operators can restart production with a single click, eliminating time-consuming re-calibration and minimizing human error. For horticultural manufacturers seeking a Plastic Thermoforming Machine that adapts to both mass and custom production needs, this machine delivers unrivaled precision and efficiency.

MACHINE STRUCTURE

PRODUCTS RANGE

FEATURES AND ADVANTAGES

1. High degree of standardization, complete functions, safe, efficient, energy-saving and hygienic.

2. It integrates mechanical, pneumatic and electrical integration, and is controlled by microcomputer and programmable controller (PLC).

3. Easy-to-operate human-machine interface, and has the function of remote connection.

4. Electric lifting, double-station large-diameter unwinding, allowing a single person to load coils weighing up to 600KG.

5. Servo feeding, stepless adjustment of sheet length, high speed, accuracy and stability.

6. The upper and lower electric heating furnaces are used for four-stage heating and protection to reduce the impact of air convection on temperature, so that the product molding is stable, from 0-400 degrees in just 3 minutes, improving production efficiency. The electric heating furnace can automatically remove the device.

7. A new real-time distributed digital dynamic hot forming temperature control system is used to control the temperature of the tile at a single point, and it has automatic compensation control, with an accuracy of ±1℃. Energy saving of about 15% and extended furnace plate service life.

8. The quick mold change system can conveniently, quickly, accurately and safely change molds, reduce machine downtime, reduce labor waste, and improve production efficiency.

9. The mold opening and closing of the forming, punching and cutting stations are controlled by servo motors, with high precision, low wear, fast speed and low noise. Each station is supported by four columns, combined with a five-point structural connecting rod, which has good stability.

10. The unique vertical stacking concept ensures continuous stacking of products.

11. Automatic counting of finished product output, with production data memory function, can store 90 sets of operating data.

12. Combined with the edge material winding device, the entire production process is clean, without burrs and waste.

13. The design of the electrical cabinet is simple and refreshing, simplifying the machine assembly and wiring installation process.

SPECIFICAITON

Sheet Materials	PP/PS/PET/PLA/PE/CPET	Air Consumption	4m³/min 0.5-0.8bar
Sheet Thickness	0.2-1.5mm	Weight	14500kg
Forming Area	730*800mm	Total Installed Power	185kw
Width Of Sheet	400-800mm	Heating Power	140kw
Upper Forming Depth	100mm	Feeding Motor	4.4kw
Bottom Forming Depth	130mm	Control Forming Plug Motor Power	4.4kw
Max Speed	48 moulds/min	Stacking Motor	2.9kw
The Longest Knife	12m	Winding Waste Of Edge Sheet Motor Power	0.4kw
Dimension	1150023502700mm	Forming Motor	7.5kw*2
Forming clamping force	750kn	Cutting Motor	7.5kw1 11kw1
Punching clamping force	900kn

PARTNER BARANDS

ESSENTIAL COMPONENT

Loading sheet part

Load automatically, lower human resource cost.

Proximity switch clever control, getting the rid of falling down of the sheet by conveying too fast.

Double stations, big diameter, reduce the frequency of changing sheet coil, improve the the production efficiency.

Max undertake roll of sheet

Weight:600kg, Diameter 800mm.

Feeding sheet part

Automatic feeding reduces human resource costs.

Actively transport the sheet and reduce the load on the conveying servo motor.

Cleverly control the proximity switch to prevent the sheet from falling too quickly during transportation.

Human-machine interface

Controlled by microcomputer and programmable controller (PLC), all action programs can be operated through the human-machine interface, simple and convenient, 15-inch touch screen.

Heater

1. Vacuum insulation cotton is installed in the heater, which has a fast reaction speed, short processing time and energy saving.

2. The furnace body is divided into two layers, the layout of the heating tiles is optimized, so that the plate is heated evenly.

Molding station

1. Mold changing auxiliary mechanism, using sliding guide rails and support rods to achieve fast mold change, saving time and effort.

2. Adopting high-power servo motor drive, high precision, high efficiency and low noise.

Molding mold

The working principle is a combination of positive and negative pressure, and some nylon plugs are used to assist stretching in the mold to make it have stronger molding ability.

There is cooling water in the mold cavity to speed up the cooling speed and make demolding easier.

Guide head structure

The workstation is supported by four columns (45# steel, hard chrome plated).

The integrated mold table (QT-600 steel) is made by a high-precision CNC milling machine. Therefore, it is wear-resistant, stable, and accurate, which prolongs the service life of the equipment.

A five-point-connecting-rod structure

This structure design provides more stable operation and faster speed.

Mold change structure

The punching hole station has the same mold changing structure as the cutting station.Greatly reduce mold change time and labor costs, improve production efficiency and safety factor, and provide convenience for your diversified product chain.

Servo motor

The station mold closing, forming auxiliary stretching, and pull-tab parts are all driven by servo motors, which have fast speed, low noise, high precision, and high efficiency.

Servo-controlled conveyor belt

Set conveyor belt parameters directly on the operation screen.

Freely adjust and control conveying length and speed.

Rewinding waste of edge sheet

Our multi-station thermoformers feature a winding unit with torque motor to efficiently collect the offcuts and wind them into a roll with one side retractable, which can be conveniently removed at the end of production.

This advanced waste management system improves operating efficiency and cleanliness, making multi-station thermoformers ideal for high-quality and sustainable production.
