Thermoforming Machine

Four-Station Plastic forming machine

Four-Station Plastic forming machine

Model：RS-730-800-4
RS-730-800-4 positive and negative pressure multi-station plastic thermoforming machine， uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...
Three-Station Plastic Thermoforming Machine

Three-Station Plastic Thermoforming Machine

Model：RS-730-800-3
RS-730-800-3 positive and negative pressure multi-station plastic thermoforming machine， uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...
Four-Station Plastic Thermoforming Machine

Four-Station Plastic Thermoforming Machine

Model：RS-730-610-4
RS-730-610-4 positive and negative pressure multi-station plastic thermoforming machine， uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...
Four-Station Plastic Thermoforming Machine

Four-Station Plastic Thermoforming Machine

Model：RS-650-450-4
RS-650-450-4 positive and negative pressure multi-station plastic thermoforming machine， uses internationally advanced plastic sheet forming technology. It is a plastic sheet forming equipment with mechanical, pneumatic and electrical integrated design. It can automatically complete all actions such as loading, feeding, heating, forming, punching, cutting, stacking, finished product tr...

Automatic Plastic Box Making Machine for Food Packaging

2026-01-04
The demand for efficient food packaging is met by the Automatic Plastic Box Making Machine from Wenzhou Rayshape Machinery Co., Ltd. As part of Elemotion Group, our company focuses on high-end automation for the food industry. Our Plastic Box Making Machine is an essential component for any modern production line, enabling the mass production of meal boxes and containers. These machines are available in multi-station configurations, often featuring three or four stations for forming, punching, cutting, and stacking. The integrated punching station in our four-station models significantly enhances efficiency. Our equipment is compatible with various materials like PP, PS, and PET, ensuring versatility for different packaging needs. With forming plate sizes reaching 730 by 800, the machine accommodates high-capacity mold cavities. Rayshape’s R&D team has designed a system where mold parameters are saved permanently. This means that once a mold is optimized, production can resume by simply clicking start. Our facility in Pingyang County, Wenzhou, adheres to a culture of continuous improvement and self-surpassing excellence. We offer comprehensive after-sales support to ensure your Automatic Thermoforming Machine runs at peak performance. By choosing Rayshape, you are investing in a system that reduces labor dependency and increases reliable output. Our history, starting with the investment in Wuhu Youhe Automation in 2021 and evolving into Wenzhou Rayshape in 2025, showcases our dedication to growth and innovation in the packaging industry. We continue to strive for excellence in developing energy-efficient plastic roll forming machines that serve the green economy.
Thermoforming Machine
Plastic Thermoforming Machine
Plastic forming machine
Plastic Container Machine
← Back Plastic Thermoforming Machine.pdf

Specifications Of Thermoforming Machines

Sheet Materials

PP/PS/PET/PLA/PE

Air Consumption

4m³/min
0.5-0.8bar

Sheet Thickness

0.2-1.5mm

Weight

12500kg

Forming Area

730*610mm

Total Installed Power

174Kw

Width Of Sheet

400-800mm

Heating Power

140kw

Upper Forming Depth

100mm

Feeding Motor

4.4kw

Bottom Forming Depth

130mm

Control Forming Plug Motor Power

4.4kw

Max Speed

45moulds/min

Stacking Motor

1.8kw

The Longest Knife

10m

Winding Waste Of Edge Sheet Motor Power

0.4kw

Dimension

11500*2350*2700mm

Forming Motor

5.5kw*2

Forming clamping force

750kn

Cutting Motor

5.5kw*2

Punching clamping force

750kn



Advantages Of Plastic Thermoforming Machines

Loading sheet part

Loading sheet part

Load automatically, lower human resource cost.

Proximity switch clever control, getting the rid of falling down of the sheet by conveying too fast.

Double stations, big diameter, reduce the frequency of changing sheet coil, improve the the production efficiency.

Max undertake roll of sheet

Weight:600kg, Diameter 800mm.

Feeding sheet part

Feeding sheet part

Automatic feeding reduces human resource costs.

Actively transport the sheet and reduce the load on the conveying servo motor.

Cleverly control the proximity switch to prevent the sheet from falling too quickly during transportation.

Human-machine interface

Human-machine interface

Controlled by microcomputer and programmable controller (PLC), all action programs can be operated through the human-machine interface, simple and convenient, 15-inch touch screen.

Heater

Heater

1. Vacuum insulation cotton is installed in the heater, which has a fast reaction speed, short processing time and energy saving.

2. The furnace body is divided into two layers, the layout of the heating tiles is optimized, so that the plate is heated evenly.

Molding station

Molding station

1. Mold changing auxiliary mechanism, using sliding guide rails and support rods to achieve fast mold change, saving time and effort.

2. Adopting high-power servo motor drive, high precision, high efficiency and low noise.

Molding mold

Molding mold

The working principle is a combination of positive and negative pressure, and some nylon plugs are used to assist stretching in the mold to make it have stronger molding ability.

There is cooling water in the mold cavity to speed up the cooling speed and make demolding easier.

Guide head structure

Guide head structure

The workstation is supported by four columns (45# steel, hard chrome plated).

The integrated mold table (QT-600 steel) is made by a high-precision CNC milling machine. Therefore, it is wear-resistant, stable, and accurate, which prolongs the service life of the equipment.

A five-point-connecting-rod structure

A five-point-connecting-rod structure

This structure design provides more stable operation and faster speed.

Mold change structure

Mold change structure

The punching hole station has the same mold changing structure as the cutting station.Greatly reduce mold change time and labor costs, improve production efficiency and safety factor, and provide convenience for your diversified product chain.

Servo motor

Servo motor

The station mold closing, forming auxiliary stretching, and pull-tab parts are all driven by servo motors, which have fast speed, low noise, high precision, and high efficiency.

Servo-controlled conveyor belt

Servo-controlled conveyor belt

Set conveyor belt parameters directly on the operation screen.

Freely adjust and control conveying length and speed.

Rewinding waste of edge sheet

Rewinding waste of edge sheet

Our multi-station thermoformers feature a winding unit with torque motor to efficiently collect the offcuts and wind them into a roll with one side retractable, which can be conveniently removed at the end of production.

This advanced waste management system improves operating efficiency and cleanliness, making multi-station thermoformers ideal for high-quality and sustainable production.
