Durable Food Box Machine for Professional Catering Supplies
|
Sheet Materials |
PP/PS/PET/PLA/PE |
Air Consumption |
3m³/min |
|
Sheet Thickness |
0.2-1.5mm |
Weight |
11000kg |
|
Forming Area |
650*450mm |
Total Installed Power |
116Kw |
|
Width Of Sheet |
370-700mm |
Heating Power |
90kw |
|
Upper Forming Depth |
100mm |
Feeding Motor |
3kw |
|
Bottom Forming Depth |
130mm |
Control Forming Plug Motor Power |
3kw |
|
Max Speed |
45moulds/min |
Stacking Motor |
1.8kw |
|
The Longest Knife |
8m |
Winding Waste Of Edge Sheet Motor Power |
0.4kw |
|
Dimension |
10210*2300*2700mm |
Forming Motor |
4.4kw*2 |
|
Forming clamping force |
600kn |
Cutting Motor |
4.4kw*2 |
|
Punching clamping force |
600kn |
|
|
Load automatically, lower human resource cost.
Proximity switch clever control, getting the rid of falling down of the sheet by conveying too fast.
Double stations, big diameter, reduce the frequency of changing sheet coil, improve the the production efficiency.
Max undertake roll of sheet
Weight:600kg, Diameter 800mm.
Automatic feeding reduces human resource costs.
Actively transport the sheet and reduce the load on the conveying servo motor.
Cleverly control the proximity switch to prevent the sheet from falling too quickly during transportation.
Controlled by microcomputer and programmable controller (PLC), all action programs can be operated through the human-machine interface, simple and convenient, 15-inch touch screen.
1. Vacuum insulation cotton is installed in the heater, which has a fast reaction speed, short processing time and energy saving.
2. The furnace body is divided into two layers, the layout of the heating tiles is optimized, so that the plate is heated evenly.
1. Mold changing auxiliary mechanism, using sliding guide rails and support rods to achieve fast mold change, saving time and effort.
2. Adopting high-power servo motor drive, high precision, high efficiency and low noise.
The working principle is a combination of positive and negative pressure, and some nylon plugs are used to assist stretching in the mold to make it have stronger molding ability.
There is cooling water in the mold cavity to speed up the cooling speed and make demolding easier.
The workstation is supported by four columns (45# steel, hard chrome plated).
The integrated mold table (QT-600 steel) is made by a high-precision CNC milling machine. Therefore, it is wear-resistant, stable, and accurate, which prolongs the service life of the equipment.
This structure design provides more stable operation and faster speed.
The punching hole station has the same mold changing structure as the cutting station.Greatly reduce mold change time and labor costs, improve production efficiency and safety factor, and provide convenience for your diversified product chain.
The station mold closing, forming auxiliary stretching, and pull-tab parts are all driven by servo motors, which have fast speed, low noise, high precision, and high efficiency.
Set conveyor belt parameters directly on the operation screen.
Freely adjust and control conveying length and speed.
Our multi-station thermoformers feature a winding unit with torque motor to efficiently collect the offcuts and wind them into a roll with one side retractable, which can be conveniently removed at the end of production.
This advanced waste management system improves operating efficiency and cleanliness, making multi-station thermoformers ideal for high-quality and sustainable production.
